Description
RPE SERIE PRO battery-operated control unit
Battery-powered control unit for locations without an electrical supply
With the battery-operated SERIES PRO control units from the Italian manufacturer RPE, you can carry out classic analog or electromechanical programming directly on one or two solenoid valves with a 9 V solenoid coil (RPE 9 - 12 VDC bistable, Hunter 9 VDC).
The control unit is installed directly on the solenoid valve (Pro100 1-zone control unit) or on two solenoid valves (Pro200 2-zone control unit). This can be operated in a valve shaft, well shaft, shed or outdoors, as it is waterproof with protection class IP68.
The battery life (please only use 9V ALKALINE) is one season. After this, it should be replaced to ensure trouble-free watering. The status of the battery is also indicated by an LED on the control unit. In addition, simple Mini-Clik sensors without an additional power source, e.g. Rain- (Rain-Clik), wind (Wind-Clik) or frost sensors (Freeze-Clik) can be connected. The Pro200 2-zone control unit can be operated with a main solenoid valve (master valve).
Important:
-Control unit is supplied without solenoid coil
-Return/recall only in complete original packaging - the original packaging is part of the item.
Facts & advantages
- Only suitable for 9 VDC impulse coils
- Battery operation: 9V alkaline (not included)
- Type: Fixed number of stations Pro100 1-zone, Pro200 2-zone
- Housing: Outdoor model (IP68)
- Number of programs: 1 program
- Watering run time: Programmable from 2 minutes to 150 minutes
- Watering frequency: 1 hour to 7 days
- Start times / watering cycles: Can be delayed from 10 minutes to 72 hours
- Memory function: Saving of watering cycles via the "SAVE" button
- Manual watering via "MAN" button
- Sensor input: 1
- Dimensions: 80 x 65 mm
DOWNLOADManual German
DOWNLOADInstructions English
