Stake assembly micro irrigation | micro ball valve sprayer

SKU: BW5078
Auswahl Steuerzone / Lieferland
from
0,76 €
incl. 19% VAT , plus shipping costs
  • Available immediately
View item details in PDF
How to measure a threaded fitting
  • Available immediately
   Variants

Product picture
Item no.
Variation
DN
Height
Total length
Price
Quantity
NDS Stake assembly micro irrigation with supply line
BW5078.285.001
Steckdorn mit Zuleitung
4mm
28,5cm Steckdorn
55cm Vinylschlauch
2,74 €*
pc.:
NDS Stake assembly micro irrigation with supply line with micro valve
BW5078.285.002
Steckdorn mit Zuleitung und Mikro Kugelhahn
4mm
28,5cm Steckdorn
55cm Vinylschlauch
3,93 €*
pc.:
TECO 310mm Stake with 300mm Rigid Riser
BW5078.310.300
Steckdorn mit 300mm starrem Steigrohr
(nur für Gewindefittings)
4mm
31cm Steckdorn + starres Steigrohr bis 24cm ausfahrbar
50cm Vinylschlauch
3,61 €*
pc.:
NDS Micro-Flo Adjustable micro-sprinkler with micro valve and male thread 0-76lph for sprinkler stake
BW5078.002.076
Sprinkler mit Kugelhahn (0-76 l/h) für Steckdorn
---
---
---
0,76 €*
pc.:

incl. 19% VAT , plus shipping costs

All dimensions are in millimeters, weights in grams. For photographic representations, we use an item size and studio lighting. The images, technical data, dimensions, and designs are non-binding. They do not constitute warranted properties or guarantees of quality or durability. We reserve the right to make changes at any time without notice. The usable dimensions are defined or emphasized, or are derived from the item description. Additional dimensions are provided solely for illustrative purposes. Please note this in the event of misuse.

   Description

Plug-in spike, pre-assembled ground spike for individual attachments such as bubblers, drippers, emitters, micro sprayers etc.

Plug-in spike variants


Various plug-in spike variants which can be connected directly to the supply pipe supply pipe and the system.


  • BW05078.285.001: Plug-in spike (28.5 cm long) fully assembled incl. micro-connection pipe (approx. 55 cm) and micro-connector
  • BW5078.285.002: Plug-in spike (28.5 cm long) completely assembled incl. micro connection line (approx. 55 cm) with micro ball valve and micro connector
  • BW5078.310.300: Plug-in spike (31 cm long) with riser pipe (30 cm long), which can be extended by 24 cm. Fully assembled incl. micro-connection line (approx. 50 cm) with micro-connector
    • For an individual watering pattern, you also need Micro sprayer or a sprinkler with thread (see above)
    BW-109 Anwendung

    Plug-in spike, pre-assembled ground spike for individual attachments

    Plug & work: Connect the fully assembled plug-in spike with the desired watering pattern of your choice to your supply line and your plants will be watered appropriately.
