Brass quick release DN 7.2 plug nipple x external thread

SKU: MF3003
Auswahl Steuerzone / Lieferland
from
1,29 €
incl. 19% VAT , plus shipping costs
  • Available immediately
View item details in PDF
How to measure a threaded fitting
  • Available immediately
   Variants

Item no.
Variation
DN
G
L
L1
L2
SW
Price
Quantity
MF3003.072.012
DN 7,2 x 1/4"
7,2
G 1/4" (13,16mm)
33
9
20
17
1,29 €*
pc.:
MF3003.072.016
DN 7,2 x 3/8"
7,2
G 3/8" (16,66mm)
33
9
20
19
1,61 €*
pc.:
MF3003.072.020
DN 7,2 x 1/2"
7,2
G 1/2" (20,96mm)
35
10
20
24
2,65 €*
pc.:

incl. 19% VAT , plus shipping costs

All dimensions are in millimeters, weights in grams. For photographic representations, we use an item size and studio lighting. The images, technical data, dimensions, and designs are non-binding. They do not constitute warranted properties or guarantees of quality or durability. We reserve the right to make changes at any time without notice. The usable dimensions are defined or emphasized, or are derived from the item description. Additional dimensions are provided solely for illustrative purposes. Please note this in the event of misuse.

   Description

Brass quick connector DN 7.2 plug nipple x male thread

Coupling DN 7.2, brass MS 58, free passage

Connection:
Plug nipple x male thread
Thread:
BSP pipe thread ISO 228-1, not self-sealing, seal with Teflon tape or similar.
Temperature:
-20°C to +100°C
Valve type:
free passage
Max. operating pressure:
PN 35 bar
medium:
Air etc.
material:
Brass MS 58
DOWNLOADRoHS confirmation HTC
DOWNLOADREACH addition brass HTC
DOWNLOAD the thread identification - or why 1" is not 25.4mm
