Description
Hunter geared sprinkler I-25 series
This robust geared sprinkler is suitable for any commercial application - the stainless steel version is a visual highlight in your garden or commercial facility!
The I-25 is very robust, extremely reliable and efficient in performance. It covers throwing distances from 11.9 to 21.6 m for a wide range of applications under different site conditions. The compact, robust design comes with an optimal stainless steel riser for best durability. The integrated shut-off valve and a wide range of high-performance nozzles round off the range. Hunter's efficient and robust I-25 geared sprinkler is designed for long life in daily use.
All I-25s come with a standard nozzle set consisting of nozzles 7, 10, 15, 20 and 25.- Model in plastic and stainless steel (riser)
- Sector adjustment 50 to 360 degrees
- Throw range 11.9 - 21.6m
- Flow rate 0.82 - 7.24m³/hour
- Flow rate 13.6 - 12.07l/min.
- Rubber protective cover fitted at the factory
- Sector adjustment through the upper part
- Fast sector locking mechanism
- Water-lubricated gearbox
- Available nozzles: 12
- Nozzle range: No. 4 to No. 28
Automatic sector return
This function causes a return to the originally set sector, even if the head has been turned manually. This ensures protection against vandalism in any environment.
Vandalism-protected decoupling mechanism
Drive mechanism protected according to the slip clutch principle, which enables manual rotation of the head without damage.
Partial and full circle in one model
Patented continuous 360° mechanism for partial and full circle in one model from 50° to 360°.
Color-coded nozzles
The nozzles are easier to distinguish, provide a quick overview and speed up installation
Stainless steel riser
Stainless steel is the ideal choice for difficult ground conditions, unpredictable climatic conditions or heavy use - or to put it simply: it just looks great!
Outlet stop valve (4.56 M)
As air in the system can cause long-term damage to the gear sprinklers and pipes, the drain stop valve prevents the pipes from draining when the system is switched off. This saves water, prevents damage and ensures a longer service life for the system.
DOWNLOAD Hunter I-25 article data
DOWNLOAD I-25 Performance data
DOWNLOAD I-25 high speed performance data
DOWNLOAD Hunter I-25 brochure
READ MORE Hunter I-25 - all data, all facts
DOWNLOAD the thread identification - or why 1" is not 25.4mm
