All measurements in millimetres, weights in grams. For the photographic representation, we use an item size both studio light. The illustrations, technical data, dimensions and designs are non-binding. We reserve the right to make changes at any time without notice. The useful dimensions are defined or shown reinforced or result from the article designation. Other dimensions are for illustrative purposes only. Please note this in case of misuse.
Description
HTC© Brass Clamp Coupling for Hose, Clamp x External Thread
Inner Ø mm
Min. wall thickness mm
Max. wall thickness mm
Max. hose A Ø
20
2.3
3.5
27
25
2.3
3.5
32
32
2.5
4.0
40
38
2.7
5.0
48
40
2.7
5.0
50
50
3.3
5.5
61
60
4.0
6.5
73
- 1 - Body
- 2 - Seal
- 3 - Press Ring
- 4 - Fixing Ring
- 5 - Nut
- Max. working pressure 10 bar at 20°C (50 years of service life)
- Max. working pressure 3 bar at 60°C (50 years of service life)
- Max. working temperature 80°C, minimum temperature -5°C
- Impressive performance in tensile test
- High resistance to thermal and mechanical stresses, weather effects, and UV rays
- Completely non-toxic, odorless: 100% usable for transporting liquid foods or drinking water
- High chemical resistance: saline solutions, chlorine, saturated hydrocarbons, gasoline, oil, as well as animal and vegetable fats
- Weather, ozone, chlorine, and UV resistant
